Fujitsu MBA3300NC 3.5″ hard drive with a storage capacity of 300GB and featuring a Fibre Channel interface.
All information about the Fujitsu MBA3300NC hard disk drive: technical parameters, failure symptoms, frequently asked questions, reviews, HDD repair and data recovery.
Fujitsu MBA3300NC Technical Details:
Manufacturer:
Fujitsu
Hard Disk Model:
MBA3300NC
Disk Family:
Enterprise Fibre Channel Series
Form Factor:
3.5″
Capacity:
300 GB (300,000,000,000 bytes)
Formatted Capacity:
Approximately 279 GB
Rotational Speed:
10000 RPM (10K)
Average Seek Time:
4.2 ms (read) / 4.8 ms (write)
Disk Interface:
Fibre Channel (2 Gb/s)
Buffer Size:
16384 KB (16 MB)
External Transfer Rate:
200 MB/s
Mean Time Between Failures (MTBF):
1,400,000 hours
Fujitsu MBA3300NC Hard Drives:
- MBA3300NC, PN CA06708-B40300DL, Fujitsu 300GB SCSI 3.5″ Hard Drive
Fujitsu MBA3300NC Failure Symptoms:
- Electrical Failure Symptoms:
Drive is powered, but shows no sign of function;
Disk knocking as the motor fails to spin;
Clicking sound as the heads search or initialize; - Mechanical Failure Symptoms:
Clicking, grinding sounds;
Completely quiet due to ” motor freeze”;
“music” tone as the disk is powered up; - Logical Failure Examples:
Accidental deletion, accidental format, file corruption, software bugs, file system corruption, viruses and malware, and many, many more. - Firmware Failure Symptoms:
drive powers up, but is not recognised by the computer;
Drive powers up, but is recognised wrongly, sometimes with nonsensical characters;
Drive freezes during booting up; - Bad Platter Area Symptoms:
Hard disk still accessible but appear to “hang” or “sluggish”;
Constant Cyclic Redundancy (CRC) errors;
Unable to access folders or files which could be seen; - Complex Failure Model
Fujitsu MBA3300NC Data Recovery & HDD Repair:
When it comes to data recovery one of the most common problems Fujitsu MBA3300NC hard drive experience is a burned circuit board (PCB). Therefore, if you need to replace the PCB, be sure to match the “PCB Number” of the current board, such as CA26348-B32306A, CA26348-B32306BA, etc.
