ST3000DM001 Seagate 3.5″ hard drive with a storage capacity of 3TB and featuring a SATA interface. ST3000DM001 Seagate Barracuda 3TB 7200RPM SATA 6Gb/s 64MB Cache 3.5-inch Hard Drive.
All information about the Seagate ST3000DM001 hard disk drive: technical parameters, failure symptoms, free asked questions, reviews, HDD repair and data recovery.
Seagate ST3000DM001 Technical Details:
- Hard Disk Model: SEAGATE ST3000DM001
- Disk Family: Barracuda 7200.12
- Form Factor: 3.5″
- Capacity: 3 TB (3 x 1 000 000 000 000 bytes)
- Number Of Disks: 3
- Number Of Heads: 6
- Rotational Speed: 7200 RPM
- Rotation Time: 8.33 ms
- Average Rotational Latency: 4.17 ms
- Disk Interface: Serial-ATA/600
- Buffer-Host Max. Rate: 600 MB/seconds
- Buffer Size: 65536 KB
- Drive Ready Time (typical): 17 seconds
- Average Seek Time: 8.5 ms
- Width: 101.6 mm (4.00 inch)
- Depth: 146.99 mm (5.79 inch)
- Height: 26.11 mm (1.03 inch)
- Weight: 626 grams (1.38 pounds)
- Required Power For Spinup: 2500 mA
- Power Required (Seek): 8.0 W
- Power Required (Idle): 5.8 W
- Power Required (Standby): 0.75 W
- Manufacturer: Seagate Technology
Seagate ST3000DM001 Hard Drives:
- ST3000DM001, W1F, SU, PN 9YN166-500, FW CC4B, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, W1F, WU, PN 9YN166-302, FW CC4C, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, Z1F, TK, PN 1CH166-048, FW AP19, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, W1F, WU, PN 1CH166-301, FW CC24, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, W1F, WU, PN 9YN166-505, FW CC82, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, WA5, WU, PN 1ER166-570, FW CC46, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, Z7P, TK, PN 1ER166-501, FW CC25, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, Z1F, TK, PN 9YN166-300, FW CC49, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, Z1F, TK, PN 1CH166-040, FW AP15, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, Z1F, TK, PN 1E6166-570, FW SC47, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, W1F, WU, PN 9YN166-571, FW CC4H, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, W1F, WU, PN 9YN166-135, FW NDP3, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, Z1F, TK, PN 9YN166-302, FW CC4C, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, S1F, SU, PN 1CH166-571, FW CC43, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, Z1F, TK, PN 1CH166-515, FW CC47, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, Z1F, TK, PN 1E6166-570, FW SC48, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, W1F, WU, PN 1CH166-510, FW CC27, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, W1F, SU, PN 1CH166-305, FW CC27, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, W1F, WU, PN 1CH166-305, FW CC27, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, Z1F, TK, PN 1CH166-306, FW CC29, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, S1F, SU, PN 1CH166-300, FW CC43, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, W1F, WU, PN 9YN166-568, FW CC96, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, S1F, SU, PN 9YN166-500, FW CC4B, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, W1F, WU, PN 9YN166-500, FW CC4B, Seagate 3TB SATA 3.5″ Hard Drive
- ST3000DM001, S1F, SU, PN 9YN166-302, FW CC4C, Seagate 3TB SATA 3.5″ Hard Drive
Seagate ST3000DM001 Failure Symptoms:
- Electrical Failure Symptoms:
Drive is powered, but shows no sign of function;
Disk knocking as the motor fails to spin;
Clicking sound as the heads search or initialize; - Mechanical Failure Symptoms:
Clicking, grinding sounds;
Completely quiet due to ” motor freeze”;
“music” tone as the disk is powered up; - Logical Failure Examples:
Accidental deletion, accidental format, file corruption, software bugs, file system corruption, viruses and malware, and many, many more. - Firmware Failure Symptoms:
drive powers up, but is not recognised by the computer;
Drive powers up, but is recognised wrongly, sometimes with nonsensical characters;
Drive freezes during booting up; - Bad Platter Area Symptoms:
Hard disk still accessible but appear to “hang” or “sluggish”;
Constant Cyclic Redundancy (CRC) errors;
Unable to access folders or files which could be seen; - Complex Failure Model
Seagate ST3000DM001 Data Recovery & HDD Repair:
When it comes to data recovery one of the most common problems Seagate ST3000DM001 Hard Disk Drive experience is burnt circuit board(PCB). So if you will need to match a replacement PCB, it is important that you note the “Board Number” of your current circuit board in addition to the hard drive’s “Model Number“.
Multiple PCB Number revisions:
100762568, 100749730, 100724095, 100717520, 100645422, 100664987, 100687658, etc.
