WD7500KMVV Western Digital 2.5″ hard drive with a storage capacity of 750GB and featuring a USB interface.
All information about the Western Digital WD7500KMVV hard disk drive: technical parameters, failure symptoms, frequently asked questions, reviews, HDD repair and data recovery.
Western Digital WD7500KMVV Technical Details:
- Hard Disk Model: Western Digital WD7500KMVV
- Disk Family: WD Elements Portable (Native USB)
- Form Factor: 2.5″
- Capacity: 750 GB (750 000 000 000 bytes)
- Number Of Disks: 2
- Number Of Heads: 4
- Rotational Speed: 5400 RPM
- Rotation Time: 11.11 ms
- Average Rotational Latency: 5.56 ms
- Disk Interface: USB 2.0 Native
- Buffer-Host Max. Rate: 480.0 Mb/seconds
- Buffer Size: 8 MB (8.0 MB)
- Drive Ready Time (typical): 3.5 seconds
- Average Seek Time: 12.0 ms
- Track To Track Seek Time: 2.5 ms
- Width: 69.85 mm (2.75 inch)
- Depth: 100.2 mm (3.94 inch)
- Height: 9.5 mm (0.37 inch)
- Weight: 117 grams (0.26 pounds)
- Acoustic (Idle): 2.4 Bel
- Acoustic (Min performance and volume): 2.4 Bel
- Acoustic (Max performance and volume): 2.6 Bel
- Required Power For Spinup: 5V (Peak 1.0A)
- Power Required (Seek): 2.5 W
- Power Required (Idle): 0.85 W
- Power Required (Standby): 0.25 W
- Manufacturer: Western Digital Corporation
Western Digital WD7500KMVV Hard Drives:
- WD7500KMVV-11BG7S0, DCM HBBTJBBN, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11TK7S1, DCM HHMTJHBN, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11BG7S0, DCM EHBVJHBB, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11BG7S0, DCM EBBT2BBB, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11BG7S0, DCM EBBTJBNN, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11TK7S1, DCM HHBT2HNN, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11A27S0, DCM HHCVJBBB, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11BG7S0, DCM HBBVJBBB, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11TK7S2, DCM HHMT2HN, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11BG7S0, DCM HHBV2HBN, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11A27S0, DCM HBCVJHBB, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11BG7S0, DCM HHBVJHNB, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11A27S2, DCM HHBV2HBB, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11TK7S1, DCM EHMTJHBB, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11BG7S0, DCM EBBVJHNB, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11BG7S0, DCM EHBTJHNB, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11A27S1, DCM HHBVJBBB, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11A27S2, DCM HBBVJHBB, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11A27S1, DCM EHBVJBBB, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11BG7S0, DCM EHBTJBBN, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11BG7S0, DCM HBBVJBB, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11BG7S0, DCM HBBVJHNB, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11TK7S1, DCM EBMTJBNN, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11BG7S0, DCM EBBVJHBB, Western Digital 750GB USB 2.5″ Hard Drive
- WD7500KMVV-11A27S1, DCM HBBVJBBB, Western Digital 750GB USB 2.5″ Hard Drive
Western Digital WD7500KMVV Failure Symptoms:
- Electrical Failure Symptoms:
Drive is powered, but shows no sign of function;
Disk knocking as the motor fails to spin;
Clicking sound as the heads search or initialize; - Mechanical Failure Symptoms:
Clicking, grinding sounds;
Completely quiet due to ” motor freeze”;
“music” tone as the disk is powered up; - Logical Failure Examples:
Accidental deletion, accidental format, file corruption, software bugs, file system corruption, viruses and malware, and many, many more. - Firmware Failure Symptoms:
drive powers up, but is not recognised by the computer;
Drive powers up, but is recognised wrongly, sometimes with nonsensical characters;
Drive freezes during booting up; - Bad Platter Area Symptoms:
Hard disk still accessible but appear to “hang” or “sluggish”;
Constant Cyclic Redundancy (CRC) errors;
Unable to access folders or files which could be seen; - Complex Failure Model
Western Digital WD7500KMVV Data Recovery & HDD Repair:
When it comes to data recovery one of the most common problems Western Digital WD7500KMVV Hard Disk Drive experience is burnt circuit board(PCB). So if you will need to match a replacement PCB, it is important that you note the “Board Number” of your current circuit board in addition to the hard drive’s “Model Number“.
Multiple PCB Number revisions:
2060-771817-001, 2060-701675-000, 2060-771754-000, 2060-701675-001, 2060-701675-004, etc.
Multiple Model Number revisions:
WD7500KMVV-11TK7S2, WD7500KMVV-11TK7S1, WD7500KMVV-11A27S2, WD7500KMVV-11A27S1, WD7500KMVV-11A27S0, WD7500KMVV-11BG7S0, etc.
